ED12

EcoDrive is a dual-stage, oil-sealed rotary vane vacuum pump equipped with a high-efficiency Permanent Magnet Motor. With a new advanced feature called “Eco Mode”, the pump runs at peak efficiency, optimizing both energy consumption and noise. This technology is ideal for industrial applications due to its performance and reliability, ensuring long-term productivity.

  • Dual Stage Oil Sealed Rotary Vane Vacuum Pump
  • cUL Approved
  • Two Shift Adjustable Gas Ballast Valve
  • Anti-suck back Design
  • Forced Oil Circulation System

Technical Specification

Pumping speed (60Hz) m3/h (CFM) 10 (5.9)
Ultimate Total Pressure without Gas Ballast mbar (Torr) 8×10-3 (6×10-3)
Ultimate Total Pressure with Gas Ballast mbar (Torr) 2 (1.5)
Power Supply Single Phase
Power Rating kW 370
Motor speed rpm 1850
Inlet/Outlet KF25
Oil capacity L 1
Noise level dB ≤53
Weight kg 14.5
lbs 32
Dimensions (L*W*H) mm 414*152*310
inch 16.3*6*12.2
